XMS01 MICRO SERVO
The high-quality micro servo has been specially chosen for the M18 because of its high precision, long life and
high quality.
XMS01 Technical Data
Speed: 0.11 sec/60° transit
Torque: 36 oz. in. / 2.6kg.cm
Size: 30 x 12 x 30 mm
Weight: 16.6g (0.58oz)
Output gear: Plastic
Wire Lead Colors
Black = ground
Red = power
Yellow = signal
MICRO BATTERY PACK
The 5-cell inline micro battery pack is designed to perfectly fi t the M18. The high-capacity NiMH 2/3A cells
provide low resistance and long life, giving excellent performance and long run times.
Charging cable #389130 included.
XT1 TRANSMITTER
• AM pistol grip transmitter
• Ergonomically designed steering wheel
• Digital proportional precise control
• Servo reversing
• Steering and throttle trims
• Throttle ATV / Adjustable Travel Volume
• Dual rate steering
• Adjustable neutral position for throttle trigger
• LED battery level indicator
• Easy crystal access
• External charging jack for battery charging
• All SMT circuitry for dependability
Specifi cations
Frequency: 27MHz
Modulation AM: Pulse Proportional Modulation (PPM)
Transmitter batteries: AAx8 (UM-3x8)
Current Drain: 200mA@12V
Weight (w/o batteries): 394g
XR1 RECEIVER
This tiny 27MHz receiver has built-in BEC (Battery Eliminator Circuit). Interchangeable crystals in following range:
Specifi cations
Frequency Band: 27MHz
Channel: 2
BEC: Yes
Single Conversion: 455KHz
Channel Spacing: 10KHz
Dimensions: 37.7x25.6x15.3mm (length x width x height)
Weight: 15g
Channel Frequency (MHz) Flag Color
1 26.995 Brown
2 27.045 Red
3 27.095 Orange
4 27.145 Yellow
5 27.195 Green
6 27.255 Blue
OTHER REQUIRED TOOLS & ACCESSORIES
You will need to purchase other items, available from your local hobby dealer, to operate and maintain your model.
• Thin, hobby-quality cyanoacrylate glue (CA glue)
• Safety glasses
• Hobby knife and/or scissors
• 8x AA alkaline batteries (for radio transmitter)
• NiMH battery charger
• HUDY Phillips screwdriver (for use with all screws on the M18)
