Xray RX8 Series - Page 4

4
TOOLS REQUIRED
Allen 1.5mm (#111545 - HUDY EXCLUSIVE Limited Edition)
Allen 2.0mm (#112045 - HUDY EXCLUSIVE Limited Edition)
Allen 3.0mm (#113045 - HUDY EXCLUSIVE Limited Edition)
Socket 5.5mm (#175535 - HUDY EXCLUSIVE Limited Edition)
Caster Clip Remover (#107612 - HUDY EXCLUSIVE Limited Edition)
Arm Reamer 4.0mm (#107644 - HUDY EXCLUSIVE Limited Edition)
Arm Reamer 3.0mm (#107643 - HUDY EXCLUSIVE Limited Edition)
Reamer (#107602 - HUDY EXCLUSIVE Limited Edition)
Cross Wrench 3mm (HUDY #107581)
Special Tool for turnbuckles, nuts (HUDY #181090)
Pocket Hobby Knife (HUDY #188981)
Scissors (HUDY #188990)
Side Cutters
(HUDY #189010)
Combination Pliers
(HUDY #189020)
Professional Multi Tool
(HUDY #183011)
HUDY Ball Joint Wrench
Alu RX8 Pinion Gear Tool
Clutch Spring Tool
(HUDY #181110)
(XRAY #349903)
(HUDY #182005)
Turnbuckle Wrench 5mm
(HUDY #181050)
Ball Allen Wrench 2.5mm (#132545 - HUDY EXCLUSIVE Limited Edition)
Ball Allen Wrench 2.0mm (#132045 - HUDY EXCLUSIVE Limited Edition)
Allen Wrench 2.5mm (#112545 - HUDY EXCLUSIVE Limited Edition)
Flywheel/Clutch Multi-Tool (HUDY #182010)
Turnbuckle Wrench 3mm
(HUDY #181030)
Tweezers
SYMBOLS USED
Part bags used
Optional parts
Assembly view
Assemble left and right sides the same way
Assemble in the specified order
Detail
Pay attention here
Assemble as many times as specified
Apply threadlock
Number of teeth
Apply oil
Follow tip here
Cut off remaining material
Ensure smooth non-binding movement
Apply grease
DETAIL
Slotted Screwdriver 4.0mm (#154055 - HUDY EXCLUSIVE Limited Edition)
Slotted Screwdriver 3.0mm (#153055 - HUDY EXCLUSIVE Limited Edition)
