Xray RX8 User Manual

5
bAG
CUTAWAY VIEW
ONE-WAY LUBE
ONE-WAY LUBE
STEP DETAIL
NOTE
ORIENTATION
OIL
OIL
1. FRONT ONE-WAy & REAR SOLID AXLE
345070
345011
345024
968140
345070
968120
345001 FRONT ONE-WAY - HARD COATED + LIGHTWEIGHT ADAPTERS
345011 FRONT ONE-WAY AXLE - BLACK COATED
345024 COMPOSITE FRONT ONE-WAY AXLE PULLEY 24T
345070 FRONT ONE-WAY AXLE OUTDRIVE ADAPTER - HUDY SPRING STEEL™ (2)
345071 FRONT ONE-WAY AXLE OUTDRIVE ADAPTER - LIGHTWEIGHT (2) (OPTION)
345800 COMPOSITE BELT PULLEY COVER SET
345100 REAR SOLID AXLE - SET
345110 REAR SOLID AXLE SHAFT
345148 COMPOSITE REAR SOLID AXLE PULLEY 48T
968120 C-CLIP 12 (10)
968140 C-CLIP 14 (10)
980324 PIN 3x24 (10)
980324
345110
345148
968120
345800
01
968120
C 12
980324
P 3x24
968140
C 14

Xray RX8 Specifications

General

Battery Type	LiPo
Drive Type	4WD
Scale	1:8
Class	Buggy
Power	Electric
Battery Voltage	14.8V
Chassis Material	Aluminum
Radio System	Not included
Suspension	Independent
