Xray RX8 User Manual

7
REAR TRACK-WIDTH
REAR ROLL CENTER
COMPOSITE SET OF BUSHINGS
1mm
0.5mm
1mm
Concentric
INITIAL SETTING
INITIAL POSITION
INITIAL SETTING
INITIAL SETTING
Eccentric
DETAIL
2.3mm
2.1mm
2x
2x
2x
2x
IN OUT
1+1 0.5
1+0.5 1
1 1+0.5
0.5 1+1
0 1+1+0.5
SHIM SHIM
Centered
2mm
Tighten gently
Tighten fully
6mm
2. REAR SUSPENSION
Bearing oil
Bearing oil
When using eccentric bushings, both
bushings must be in same position.
OPTION:
#345290 Alu shim 12x15x1.0mm (4)
NOTE ORIENTATION
903256
SFH M2.5x6
962120
S 12x15x0.5
962121
S 12x15x1.0
941218
BB 12x18x4
901303
SB M3x3
306219
SHIM 3x6x2
901316
SB M3x16
980322
P 3x22
OIL
OIL
ASSEMBLED VIEW
ASSEMBLED VIEW
ASSEMBLED VIEW
ASSEMBLED VIEW

Xray RX8 Specifications

General

Battery Type	LiPo
Drive Type	4WD
Scale	1:8
Class	Buggy
Power	Electric
Battery Voltage	14.8V
Chassis Material	Aluminum
Radio System	Not included
Suspension	Independent
