1. FRONT SUSPENSION
CASTER ADJUSTMENT
VIDEO TECH TIP
▶
EXTRA SHIM UNDER FRONT BALL
(INITIAL SETTING)
ALTERNATIVE FRONT POSITION
ALTERNATIVE REAR POSITION
FRONT WHEELBASE ADJUSTMENT
Longer wheelbase is recommended for bigger tracks
with longer sweepers. Makes the car more stable and
easier to drive.
Shorter wheelbase allows the car to rotate better in corner
to maintain cornering speed. Recommended for tight,
technical tracks or tracks with numerous 180° hairpin
corners.
CASTER ADJUSTMENT SETTING
Caster is adjusted by the shims placed
Please see the table beneath the to
understand how to set caster.
RIDE HEIGHT AND CASTER ADJUSTMENT
The number of washers and shims used
affects the ride height and caster of the
car, so determine the proper amount of
shimming based on a tire diameter and
wished caster.
INITIAL SETTING
0.2mm - SILVER
0.4mm - BLACK
0.6mm - GOLD
0.6mm - GOLD
DETAIL
