Xsarius SNIPE4 - 7-2. Equipment for Installation; 7-3. Instruction for Installation

ENGLISH - 15
※ Mounting plate direction
Silicone
Allen wrench
Cleaner
Masking tape
Power drill
2mm drill bit, over 20mm drill bit
Mounting plate
M6 × 15(8) , M4 ×20(14)
PI box
PI cable (1.5m)
Signal cable (10m)
Remote conteol, Remote conteol bracket
Cigarette lighter adaptor (Power input cable)
Cable holder & gland
7-2. Equipment for installation
7-3. Instruction for installation
A. Mounting plate installation on a vehicle roof
1
2
10
11
4
13
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
8
5
6
14
Put aside the mounting plate to apply silicone
within the attached tape line but leave 2cm
inward gap from the line
Attach masking tape outside of the mounting
plate by 5mm away from the plate edges
A-4
A-2
FRONT
Clean the surface with cleaner
A-3
A-1
Locate mounting plate in the center of the
vehicle roof
5
7
Driving direction
12
9
