Xsarius SNIPE4 - Operating Instruction; 3-1. Connection Diagram

ENGLISH - 6
3. Operating Instruction
3-1. Connection diagram
Portable use
Attach four(4) base pads to the bottom of antenna
base.
Turn on the PI power after all cables connections are complete.
When not using the antenna, turn o the PI power.
MAIN UNIT
PI box
Signal cable (10 m)
PI cable (1.5 m)
STB
TV
Power input cable
Ignition
Cigar jack
Remote control Mobile App
