30
How to Use Spray Tips
The quick–connect on the nozzle extension allows you to switch between
four different quick connect spray tips. Spray tips can be changed while
pressure washer is running once spray gun trigger safety lock is
engaged. The spray tips vary the spray pattern as shown above.
Follow these instructions to change spray tips:
1. Pull back collar on quick–connect and pull current spray tip off. Store
spray tips in holder provided on the handle. Storing nozzles in the
designated holder will help prevent debris clogging the tip.
2. Select desired spray tip:
• For gentle rinse, select white 40° spray tip.
• To scour surface, select yellow 15° or red 0° spray tip.
• To apply detergent, select black spray tip.
3. Pull back on collar, insert new spray tip and release collar. Tug on
spray tip to make sure it is securely in place.
Usage Tips
• For most effective cleaning, keep spray tip from 8 to 24 inches away
from cleaning surface.
• If you get spray tip too close, especially using a high pressure spray tip,
you may damage surface being cleaned.
WARNING
The high pressure stream of water that this equipment
produces can cut through skin and its underlying
tissues, leading to serious injury and possible
amputation.
• NEVER exchange spray tips without the trigger safety lock engaged
on the spray gun.
• DO NOT twist spray tips while spraying.
0
o
RED
40
o
WHITE
soaper
BLACK
15
o
YELLOW
spray tips
