Analog/digital input # 1 is the BROWN WIRE OF CABLE “A”. It may be used as either an analog or
digital input.
Analog input # 2 is the YELLOW WIRE OF CABLE “A”. Analog only.
Analog input # 3 is the BLUE WIRE OF CABLE “B”. Analog only.
Analog input # 4 is the GREEN WIRE OF CABLE “B”. Analog only.
Digital input # 5 is the GREEN WIRE OF CALBE "A". Digital only.
