The Xirgo Technologies XT-6300 Series is a robust telematics device designed for vehicle tracking, monitoring, and data acquisition. This installation guide, version 1.3, provides comprehensive information for setting up and configuring the device.

Function Description:

The XT-6300 Series serves as a versatile telematics unit, capable of tracking vehicle location, monitoring various vehicle parameters, and transmitting data over cellular networks. It integrates GPS for precise positioning, cellular modules for communication, and a range of input/output interfaces for connecting to vehicle systems and external sensors. The device is designed to be securely installed within a vehicle, with provisions for accelerometer calibration and secure mounting.

Important Technical Specifications:

Cellular Wireless Technology:

2G/GSM/GPRS/EGPRS: Supports 850/900/1800/1900 Bands. Models include XT6350 and XT6355.
3G (UMTS): Supports 850/1900 Bands (Bands V, II). Model is XT6360.
CDMA (1xRTT): Supports 850/1900 Bands. Model is XT6350.

GPS Specification:

Receiver: 56 channels.
Receiver Tracking Sensitivity: -162 dBm.
Receiver Cold Start: -148 dBm.
CEP Accuracy: +/- 2.5m.
TTFF (Time To First Fix):
- Cold Start: <29 seconds.
- Hot Start: <1 second.
- (Notes: TTFF based on all satellites at -130 dBm; Accuracy: CEP, 50%, 24 hours static, -130 dBm, > 6 SVs).

Hardware Options:

3-axis Accelerometer: Integrated for motion detection and impact sensing.
BT/BTLE (Bluetooth/Bluetooth Low Energy): For short-range wireless communication.
Last Gasp Back-up Battery: Internal 250 mAh rechargeable Li-Ion battery, providing power during main power loss.

Power Requirements:

D.C. Power: 9-32V.

Physical Connection:

Data Connector:
- 24-pin Molex Main connector.
- 14-pin Molex OBD/J-Bus connector.
Antenna: Internal Cellular/GPS/BT.
SIM Access (2G/3G): N/A (likely embedded or internal).
Programming: Serial, using Xirgo Device Manager (XDMI).

Mechanical:

Case Material: PC2407, Black.
Dimension: 3.05" x 3.08" x 0.8".
Weight: 3 oz.
Operating Temperature: -30C to +75C.

Certifications:

Product:
- (CDMA) FCC ID: GKM-XT6350.
- (3G) FCC ID: GKM-XT6360.
- IC: 10281A-XT6350.
Carrier: Verizon, ATT.

Current Consumption:

Deep Sleep: 3 mA.
Standby: 10 mA.
Active Transmit/Receive: 65 mA.

Connectors IO Interface:

The device features two main Molex connectors:

Main 24-pin Molex Connector (IO Interface):
- Part Number (connector): 43025-2400.
- Part Number (male pins): 43031-0002.
- Pinout includes 12/24 Volt Power, LED+12V (for panic LED), Ground (Main Battery GND, Panic GND, Garmin FMI GND, Spare GND), Ign Out (Buzzer +12V/24V with 560 ohm), multiple IN (Ignition Sense, Panic inputs), multiple OUT (Buzzer GND, Panic LED), Garmin PWR (12V/2A Switched), Serial Port-1 TX/RX/GND (Garmin FMI), Serial Port-2 TX/RX/GND, 1-Wire Serial Main (iButton Data default), 1-Wire Serial Sec., and Ext. ADC.
OBD 14-pin Molex Connector (OBD2/JBUS/SWC):
- Part Number (connector): 043025-1400.
- Part Number (male pins): 43031-0002.
- Pinout includes CAN_HS_H/L, J1708_RXD/TXD, L_LINE, J1850_NEG/POS, CAN_MS_H/L, SWC_BUS, K_LINE, GND, and Vehicle Power (VBAT). These pins are mapped to 9 Pin J-Bus and 6 Pin J-Bus standards.

Usage Features:

LED Definition:

The device incorporates several LEDs to indicate its operational status:

BASE UNIT Cellular (Amber):
- LED OFF: Searching for Cellular Network.
- Solid: Cellular Carrier Lock.
BASE UNIT GPS (Green):
- Solid: Searching for satellite.
- Blinking: GPS Lock.
Optional Bluetooth (Blue): TBD (status not yet defined in this version).

Device Mounting Options:

The XT6350 must be securely installed within the vehicle.
A loose unit can prevent the accelerometer from calibrating correctly, especially when the vehicle is in motion.
The device provides space for a tie strap to secure it, ensuring stable mounting.

Device Configuration using PC:

Connectivity: An RS-232 to USB TTL converter cable is required. Serial Port #2 on the XT-63XX device is used for configuration.
- Connect the XT63XX Tx wire to the TTL converter cable Rx wire.
- Connect the XT63XX Rx wire to the TTL converter cable Tx wire.
- Connect the XT63XX ground wire to the TTL converter cable ground wire.
Terminal Application Settings: Use a terminal application to connect to the COM port associated with the TTL converter cable with the following settings:
- Bits per second: 115200.
- Data bits: 8.
- Parity: None.
- Stop bits: 1.
- Flow control: None.
Loading Script Files:
- Use the command :grscr x 2 "D_Script3_20.bin>" to load a script file.
- Upload the file using the terminal program.
Loading Parameter Files:
- Use the command :gycfg x 2 "Name of file" to load a parameter file.
- Upload the file using the terminal program.
Saving Configuration:
- Use the command :vycfg to save the current configuration.

Maintenance Features:

While the guide doesn't explicitly detail "maintenance features" in a separate section, the configuration options and secure mounting instructions imply aspects of device upkeep and reliability:

Firmware and Parameter Updates: The ability to load script and parameter files via a PC connection allows for remote or local updates to the device's operating software and settings, ensuring it remains current and functional.
Secure Installation: The emphasis on secure mounting helps prevent physical damage from vibrations or impacts, contributing to the device's longevity and consistent performance.
Backup Power: The internal rechargeable Li-Ion battery provides a "last gasp" capability, ensuring critical data can be transmitted even if the main vehicle power is interrupted, which is a key aspect of data integrity and device reliability.
LED Indicators: The status LEDs provide immediate visual feedback on the device's operational state (cellular network connectivity, GPS lock), aiding in quick troubleshooting and verification of proper functioning after installation or during operation.

XT XT-6300 Series - Document Change History
