PREFACE
Dear customers,
Sincerely thank you to become users of Xiangtong products! Xiangtong X-mill
500 series of five-axis dental milling machines are quality equipment of the compa-
ny for dental denture processing. To use the equipment better, you are wanted to
read the operating manual provided with the equipment before starting to operate
the equipment. The manual is intended for user’s installation, commissioning,
processing, troubleshooting and routine maintenance. Please pay attention to the
relevant precautions, so as to avoid equipment damage and personal injury due to
misuse.
X-mill 500 five-axis dental milling machine is made of high-quality components,
materials, and specially developed motion control technology. The machine adopts
high precision and high intelligence integrated design and assembly, uses dry
milling processing, is compatible with zirconia block/wax/PMMA. The machine
features double dust prevention, easy operation and digital, multi-sensor monitor-
ing and design free of maintenance.
The milling machine is precise processing equipment. To ensure the safety of
operators and the machine, it should be operated by professional operators. If you
have any questions, please contact us in a timely manner, and our professionals
will always be ready to help you.
Shenzhen Xiangtong Medical Technology Co., Ltd.
Address: 4/F, Building No.1, Block 2, South Section, HongHualing Industry Zone,
Xili Town, Nanshan District, Shenzhen
Postal code: 518055
Tel.: (+86)0755-86001801 86001802 86001803 86001804
Fax: (+86)0755-86001486
Email: szxtgd@xianton.com
Website: www.xtcera.com
CONTENTS
Preface I
Chapter 1: Introduction to X-Mill 500 Five-Axis Dental Milling machine 1
1-1 Product Introduction 1
1-2 Shape Structure 2
1-3 Technical Parameters 4
1-4 Operating Environment & Requirements 4
Chapter 2: Installation and Commissioning 5
2-1 Equipment Installation prcautions 5
2-2 Equipment Commissioning 5
Chapter 3: Pilot Run and Processing 8
3-1 Pilot Run 8
3-2 Processing Run 10
3-3 Selection and Replacement of Burs 11
3-4 Special notes for holder installation
13
3-5 Troubleshooting 14
Chapter 4: Maintenance and Precautions 15
4-1 Maintenance Instructions: 15
4-2 Special Statement 16
4-3 Precautions 16
Chapter 5: Common Abnormality and Countermeasures 18
Appendix I: overall Equipment Operation Flow Chart 19
Appendix II: Reference for Processing File Information 20
