Xterra ERG160 User Manual

14
ERG160 Rower
#100 1pc
#50 M
12*160 4pcs
#64 Ф18*Ф13*26 2pcs
STEP-5
64
50
50
64
1
12L
12R
Pedals
5
1. Attach the Left Pedal (12L) onto the Main Frame (1) and secure with 2 Hex
Head Bolts (50) and 1 Pedal Bushing (64).
2. Repeat the same procedures to assemble the Right Pedal (12R) to the Main
Frame (1).
#100 1pc
#50 M12*160 4pcs
#64 Ф18*Ф13*26 2pcs
STEP-5
64
50
50
64
1
12L
12R
ERG160 Assembly Instructions
