XTM XTM477PK - Radio Controls

6
RADIO LAYOUT
RADIO LAYOUT
RADIO CONTROLS
FIG. 1
RB
SC
BP
Push To Talk Button
Microphone
Fixed
Microphone cord
(Non removable)
Memory/
Function
Scan Channel
DOWN
Channel
UP
LCD Display
Power
ON/OFF
Volume
Control
Green Receive
Light
Red Transmit
Light
Selcall Button Instant Channel Button
