XtraVac860A - E
Spare Parts List
NO. Description Component No. NO. Description Component No.
01
N one -
26
Round head screw 004 - 04 - 03 - 003
02
Sealing pad 009 - 10 - 05 - 010
27
Spring washer 004 - 06 - 02 - 007
03
Sealing unit 002 -02- 01 - 01 2
28
Round head screw 004 - 04 - 03 - 005
04
Air bag cover 004 - 03 - 02 - 007
05
Air bag 009 - 18 - 02 - 007
06
Round head screw 004 - 04 - 03 - 003
07
Round head screw 004 - 04 - 03 - 003
08
Spring washer 004 - 06 - 02 - 00 7
09
Spring washer 004 - 06 - 02 - 007
10
U- shape board 004 - 03 - 07 - 00 2
11
Air bag support 002 - 03 - 05 - 007
12
Round head screw 004 - 04 - 03 - 013
13
PE pad 003 - 03 - 01 - 002
14
Rubber pad 009 - 09 - 01 - 011
15
O- ring 009 - 09 - 01 - 002
16
PE pad 003 - 03 - 01 - 001
17
Fixing nut 003 - 17 - 02 - 001
18
Rubber pad 009 - 09 - 01 - 012
19
Air bag fixing screw 004 - 17 - 23 - 003
20
Round head screw 004 - 04 - 03 - 013
21
PE pad 003 - 03 - 01 - 002
22
Rubber pad 009 - 09 - 01 - 011
23
U- shape board 004 - 03 - 07 - 00 3
24
Spring washer 004 - 06 - 02 - 007
25
Round head screw 004 - 04 - 03 - 003
