XtremepowerUS 62FT - Parts List and Diagram

No. Part No. Description QTY
1 5024015000 Pressure Gauge 1
2 647311973000 Manual Air Relief Assembly 1
3a 47311901080 Upper Filter Body(small) 1
3b 47311905080 Upper Filter Body(large) 1
4 647311971000 Clamp System 1
5 5431146080 O-Ring 1
6 5758083000 Air Relief Filter 1
7 5431073080 O-Ring 1
8 47311913001 Adaptor 1
9a 5748122001 PVC Pipe (short) 1
9b 5748123001 PVC Pipe (long) 1
10 47311908001 Adaptor(short) 1
11 47311909001 Adaptor(long) 1
12a
Filter Element cluster
(H=608mm)
1
12b
Filter Element cluster
(H=792mm)
1
13 47312507080 Filter Element Locator 1
14 47311902080 Lower Filter Body 1
15 47312508080 Adaptor plug screw 2
16 5471147080 O-Ring 2
17 Retainer nut 1
18
5244060000Seal
2
19
47312512001
Top Collector Manifold
1
20b
Long Bolt
1
21 91215001 1 1/2 Drain Plug w/O-Ring 1
5233042000
5227066000
20a
Short Bolt
1
5227065000
647312572
647312571
a-20b
