2 Structure
2.1 Multiple-functionCombinationCable
You can refer to the following figure for multiple-function combination cable information. See Figure
2-1.
Figure 2-1
Please refer to the following sheet for detailed information.
Port Name
Function
Connection
Note
1.LAN
Network port
Ethernet
port
Connect to standard Ethernet cable.
2.DC12V
Power input
port
/
Power input port. Input DC 12V.
2.2 FrameworkandDimension
Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and
Figure 2-3.
