Xvive U2 User Manual

Note:
In an emergency, power can be supplied via a USB wall
adapter however, the battery life will be reduced.
* Always store U2 at room temperature
* When storing the unit, please check the battery
state regularly and charge if necessary.
0:15 min
0:30 min
1 hour
2 hours
30 min
1 hour
2 hours
5 hours
CHARGING TIMES BATTERY LIFE
Connect to the socketConnect Power
BATTERIES AND CHARGING
09

Xvive U2 Specifications

General

Type	Wireless Guitar System
Frequency Response	20Hz - 20kHz
Battery Life	Up to 5 hours
Power Source	USB charging
Operating Band	2.4GHz
Compatibility	Instruments with 1/4" output jack
Battery	Rechargeable lithium-ion
Included	Transmitter, Receiver, USB Charging Cable
Connectors	1/4 inch jack
Latency	Less than 6ms
Dimensions	Transmitter: 2.36" x 1.18" x 0.59" (60mm x 30mm x 15mm); Receiver: 2.36" x 1.18" x 0.59" (60mm x 30mm x 15mm)
Weight	Transmitter: 1.06 oz (30g); Receiver: 1.06 oz (30g)
