XVST MAGIC 04 - Specifications

1-2. Specifications(MAGIC)
CH 1 Product Introduction
Model
MAGIC Series
MAGIC 4 MAGIC 8 MAGIC 8P MAGIC 16P MAGIC 16M
Compact case 19” rack type
Camera in
p
ut
4 BNC 8 BNC 8 BNC 16 BNC 16 BNC
Video
Individual HD/Analog sel
ectable
All Hybrid(Patent)
Available source
720p25,30,50,60/1080p25,30,50,60/1080i50,60/Composite/960H/Mixed
Output
1 HDMI+1 VGA (simultaneously) / 1 Programmable SPOT with OSD
Audio
Audio input
4 RCA 8 RCA 16 RCA
Output
1RCA
Output
1
RCA
Sensor In
4 (NC/NO) 8 (NC/NO) 16(NC/NO)
Alarm out
1 relay 6 TTL, 2 relay 14 TTL, 2 relay
Operating System
Embedded Linux OS
Display
Speed
Real Time
Resolution (Pixel)
1280X1024, 1280X720, 1920X1080
Split screen
1,4 1,4,6,8,9 1,4,6,8,9 1,4,6,8,9,13,16
Recording
CODEC
H.264 / JPEG for 3G, Dual CODEC
Resolution (Pixel)
720p, 1080p,1080i, 960H, 720H, Mixed
Picture quality
4 steps (Super, High, Medium, Low)
Speed
NTSC area
PAL area
120fps@1080p
100fps@1080p
240fps@1080p
200fps@1080p
240fps@1080p
200fps@1080p
480fps@1080p
400fps@1080p
480fps@1080p
400fps@1080p
Playback
Display
1,4 1,4,8 1,4,8 1,4,6,8,9,13,16
Search mode
Calendar, Event ,POS , Panorama, Thumbnail
Speed
NTSC
PAL
60fps@1080p
100fps@1080p
120fps@1080p
200fps@1080p
120fps@1080p
200fps@1080p
120fps@1080p
200fps@1080p
480fps@1080p
400fps@1080p
Fast/Slow speed
Normal, REW & FF [recorded speed x2, x4, x8, x16,x32,x64,x1/2,x1/4], Frame to
frame Pause
7
frame
,
Pause
