XXL MC6DSP User Manual

Conexiones sección Máster
1. FX FOOTSWITCH* – jack
6,35mm
2. AUX send – jack 6,35mm
3. (Aux send) INSERT** – jack
6,35mm de 3 conectores
4. 2TR (play)*** - par pin-jack
5. 2TK REC*** - par pin-jack
6. G1 output – jack 6,35mm
7. G2 output – jack 6,35mm
8. G1 INSERT** – jack 6,35mm
de 3 conectores
9. G1 INSERT** –jack6,35mm de
3 conectores
10. LEFT BALANCED– 3-pin XLR
11. LEFT - jack 6,35mm
12. LEFT INSERT** –jack 6,35mm
de 3 conectores
13. RIGHT BALANCED – 3-pin XLR
14. RIGHT - jack 6,35mm
15. RIGHT INSERT** –jack 6,35mm
de 3 conectores
AUX & FX section
16. FX - display
17. FX PROGRAM (PUSH)**** -
selector
AUX RETURNS section*****
18. FX TO AUX - perilla
19. FX TO L/R – perilla
20. FX TO G1/G2 - perilla
AUX SEND section
21. AUX SEND - perilla máster
FX RETURNS section
22. FX RETURN –fader máster
23. (FX RETURN) MUTE – tasto &
LED
24. (FX RETURN) L/R – interruptor
de asignación
25. (FX RETURN) G1/G2 –
interruptor de asignación
26. (FX RETURN) PFL – interruptor
Master & Indicators
2TRACK return section******
27. 2TK TO L/R - perilla
28. 2TK TO G1/G2 - perilla
G1 & G2 TO L/R section*******
29. PAN G1 - perilla
30. G1 TO L/R - interruptor de
asignación
31. G1 - fader máster
32. PAN G2 - perilla
33. G2 TO L/R – interruptor de
asignación
34. G2 - fader máster
Indicators section
35. 10 LEDs Indicadores del nivel
de salida********
36. (Power) ON - indicador
37. PFL - indicador
38. Indicator Mode –
interruptor********
Master controls section
39. HEADPHONE – salida jack
6,35mm estéreo
40. +48V – indicador
41. PHONES LEVEL – máster perilla
42. PHANTOM – máster
interruptor
43. LEFT - fader máster
44. RIGHT - fader máster
Lea la página 6 para notas
Connexions de la section Master
1. FX FOOTSWITCH* –Jack 6,35
mm
2. AUX send - Jack 6,35 mm
3. (Aux send) INSERT** – Jack
6,35 mm 3 points
4. 2TR (play)*** - Paire de prises
RCA
5. 2TK REC*** - Paire de prises
RCA
6. G1 output - Jack 6,35 mm
7. G2 output - Jack 6,35 mm
8. G1 INSERT** – Jack 6,35 mm 3
points
9. G1 INSERT** – Jack 6,35 mm 3
points
10. LEFT BALANCED– XLR 3
broches
11. LEFT - Jack 6,35 mm
12. LEFT INSERT** – Jack 6,35 mm
3 points
13. RIGHT BALANCED – XLR 3
broches
14. RIGHT - Jack 6,35 mm
15. RIGHT INSERT** – Jack 6,35
mm 3 points
AUX & FX section
16. FX - Afficheur
17. FX PROGRAM (PUSH)**** -
Sélecteur
AUX RETURNS section*****
18. FX TO AUX - Bouton
19. FX TO L/R - Bouton
20. FX TO G1/G2 - Bouton
AUX SEND section
21. AUX SEND – Bouton Master
FX RETURNS section
22. FX RETURN – Fader Master
23. (FX RETURN) MUTE – Touche &
DEL
24. (FX RETURN) L/R –
Commutateur d’assignation
25. (FX RETURN) G1/G2 –
Commutateur d’assignation
26. (FX RETURN) PFL –
Commutateur
Master & Indicators
2TRACK return section******
27. 2TK TO L/R - Bouton
28. 2TK TO G1/G2 - Bouton
G1 & G2 TO L/R section*******
29. PAN G1 - Bouton
30. G1 TO L/R - Commutateur
d’assignation
31. G1 - Fader master
32. PAN G2 - knob
33. G2 TO L/R – Commutateur
d’assignation
34. G2 – Fader master
Indicators section
35. Indicateur de niveau de sortie
à 10 DEL********
36. (Power) ON - Indicateur
37. PFL - Indicateur
38. Indicator Mode –
Commutateur********
Master controls section
39. HEADPHONE –Jack 6,35 mm
de sortie stéréo
40. +48V – Indicateur
41. PHONES LEVEL – Bouton
Master
42. PHANTOM – Commutateur
Master
43. LEFT – Fader Master
44. RIGHT – Fader Master
Voir les notes page 6
Buchsen in der Master-Sektion
1. FX FOOTSWITCH* –6,35mm
Klinke
2. AUX send - 6,35mm Klinke.
3. (Aux send) INSERT** –
3polige, 6,35mm Klinke.
4. 2TR (play)*** - Paar Pin-Jack
5. 2TK REC*** - Pin-Jack Paar
6. G1 output - 6,35mm Klinke
7. G2 output - 6,35mm Klinke.
8. G1 INSERT** 3polige, 6,35mm
Klinke
9. G1 INSERT** – 3polige
6,35mm Klinke.
10. LEFT BALANCED– 3-Pin XLR
11. LEFT - 6,35mm Klinke
12. LEFT INSERT** – 3polige
6,35mm Klinke
13. RIGHT BALANCED – 3-Pin XLR
14. RIGHT - 6,35mm Klinke.
15. RIGHT INSERT** – 3polige
6,35mm Klinke
AUX & FX section
16. FX - Display
17. FX PROGRAM (PUSH)**** -
Wähler
AUX RETURNS section*****
18. FX TO AUX - Drehregler
19. FX TO L/R - Drehregler
20. FX TO G1/G2 - Drehregler
AUX SEND section
21. AUX SEND - Master Drehregler
FX RETURNS section
22. FX RETURN – Master Fader
23. (FX RETURN) MUTE – Taste &
LED
24. (FX RETURN) L/R – Assign-
Schalter
25. (FX RETURN) G1/G2 – Assign-
Schalter
26. (FX RETURN) PFL – Taste
Master & Indicators
2TRACK return section******
27. 2TK TO L/R - Drehregler
28. 2TK TO G1/G2 - Drehregler
G1 & G2 TO L/R section*******
29. PAN G1 - Drehregler
30. G1 TO L/R – Assign-Schalter
31. G1 – Master Fader
32. PAN G2 - Drehregler
33. G2 TO L/R – Assign-Schalter
34. G2 - Master Fader
Indicators section
35. Ausgangs-Pegel-Anzeige
Balken mit 10 LED ********
36. (Power) ON - Anzeige
37. PFL - Anzeige
38. Indicator Mode –
Schalter********
Master controls section
39. HEADPHONE –6,3mm Stereo-
Ausgangs-Buchse
40. +48V – Anzeige
41. PHONES LEVEL – Master-
Drehregler
42. PHANTOM – Master-Schalter
43. LEFT - Master Fader
44. RIGHT - Master Fader
Lesen Sie die Anmerkungen auf
Seite 6
Connessioni sezione Master
1. FX FOOTSWITCH* – presa da
6,35mm.
2. AUX send - presa da 6,35mm.
3. (Aux send) INSERT** – presa “a
tre poli” da 6,35mm.
4. 2TR (play)*** - coppia pin-jack
5. 2TK REC*** - coppia pin-jack
6. G1 output - presa da 6,35mm.
7. G2 output - presa da 6,35mm.
8. G1 INSERT** – presa “a tre
poli” da 6,35mm.
9. G1 INSERT** – presa “a tre
poli” da 6,35mm.
10. LEFT BALANCED– 3-pin XLR
11. LEFT - presa da 6,35mm.
12. LEFT INSERT** – presa “a tre
poli” da 6,35mm.
13. RIGHT BALANCED – 3-pin XLR
14. RIGHT - presa da 6,35mm.
15. RIGHT INSERT** – presa “a tre
poli” da 6,35mm.
AUX & FX section
16. FX - display
17. FX PROGRAM (PUSH)**** -
selettore
AUX RETURNS section*****
18. FX TO AUX - manopola
19. FX TO L/R - manopola
20. FX TO G1/G2 - manopola
AUX SEND section
21. AUX SEND – manopola master
FX RETURNS section
22. FX RETURN –fader master
23. (FX RETURN) MUTE – tasto &
LED
24. (FX RETURN) L/R – interruttore
di assegnazione
25. (FX RETURN) G1/G2 –
interruttore di assegnazione
26. (FX RETURN) PFL – interruttore
Master & Indicators
2TRACK return section******
27. 2TK TO L/R - manopola
28. 2TK TO G1/G2 - manopola
G1 & G2 TO L/R section*******
29. PAN G1 - manopola
30. G1 TO L/R – tasto di
assegnazione
31. G1 – fader master
32. PAN G2 - manopola
33. G2 TO L/R – interruttore di
assegnazione
34. G2 – fader master
Indicators section
35. Indicatore del livello di uscita
a 10 LED********
36. (Power) ON - indicatore
37. PFL - indicatore
38. Indicator Mode –
interruttore********
Master controls section
39. HEADPHONE –presa di uscita
stereo da 6,3mm.
40. +48V – indicatore
41. PHONES LEVEL –manopola
master
42. PHANTOM – interruttore
master
43. LEFT - fader master
44. RIGHT - fader master
Per le note leggi pag.6
