XYZ Machine Tools SMX 4000 User Manual

158
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
ITEM
P/N
DESCRIPTION
QTY
71
ABBA66
NEEDLE BEARING:BA66
1
72
AK0203100
KEY:2x3x10
1
73
AK0304160
KEY:3x4x16
1
74
AK0305250
KEY:3x5x25
1
75
AK0404100
KEY4x4x10
2
76
AK2503450
CLUSTER GEAR KEY:2.5x3x45
1
77
AKP103120
ROLL PIN: Ø 3x12L
2
78
AKP103140
PIN: Ø 3x14L
2
79
AKP103200
ROLL PIN: Ø 3x20L
2
80
AKP103200
PIN: Ø 3x20L
1
81
AKP105140
PIN: Ø 5x14L
1
82
AKP105150
DOWEL PINS: Ø 5x15L
1
83
AKP105200
ROLL PIN: Ø 5x20L
1
84
ANI102014
NUT:1/4"-20NC-2L
1
85
ANI112012
QUILL HANDLE LOCK NUT:1/2"-12NC-12L
1
86
ARS112018
SNAP RING
1
87
ASI614010
SOCKET SET SCREW:1/4"-20NC-1"L
7
88
ASI614034
SOCKET SET CAP SCREW:1/4"-20NC-3/4"L
1
89
ASI614038
SCREW:1/4"-20NC-3/8"L
1
90
ASI614112
SCREW:1/4:-20NC-1 1/2"L
4
91
ASI6316012
SCREW:3/16"-24NC-1/2"L
7
92
ASI6316014
SCREW:3/16"-24NC-1/4"L
1
93
ASI6316058
R.HEAD SCREW:3/16"-24NC-5/6"L
1
94
ASI6516014
SET SCREW:5/16"-18NC-1/4"L
1
95
ASM604025
SOCKET SET SCREW:M4x0.7-25L
1
96
ASM608016
SCREW:M8x1.25-16L
1
97
OIL CLIP
1
98
GREASE TUBE
1
99
STEEL BALL: 3"/16
1
100
SPRING
2
101
COMPRESSION SPRING
2
102
COMPRESSION SPRING
2
103
COMPRESSION SPRING
1
104
COOLANT NOZZLE:PT1/8"
1
105
LOCKING NUT:M12x1.0-6L
1
106
LOCKING NUT:M8x1.25-1.2L
1
