X, Y, and Z-axis Gibs are not
adjusted properly
Check the adjustment of the X, Y, and Z-axis Gibs using the X,
Y, and Z-axis Gib adjustment procedures.
Binding in the Drive Train
Check Repeatability using the Repeatability and Positional
Accuracy procedure. Check the torque reading of the Drive
Train. Step by step, carefully inspect the Drive Train for any
binding. It may be necessary to disassemble and then
reassemble the Drive Train. See Mechanical Drive Train (X, Y)
Section 4.2
Servo Drive failure
See Servo Drive Section 4.5
Motor failure
See Motor Section 4.4
3.2.3 Axis Will Not Jog
The system powers up but will not respond to the jog command.
Do the following Service Codes and procedures:
 Code 33 Software Identification. This is needed if you call Customer Service
 Code 100 Axis open loop test. Used to check the maximum feedrate of an axis and if the
encoders are counting
Possible Cause
Check This
Improper Boot-up
Shut down the system and wait 10 seconds before rebooting
E-Stop is pressed in
Check E-Stop. Especially if both axes will not jog
E-Stop reset button
Press the E-Stop reset button on the side of the pendant
Servo Drive failure
Especially, if only one axis will not jog;
See Servo Driver Section 4.5
Shorted motor
See Motor Section 4.4
Poor cable or wiring connections
See Electrical Connection Section 2.12
Computer/Pendant failed
See Computer/Pendant diagnostics Section 4.3
3.2.4 Axis Motor Motion is not Smooth
While under motor power, the motion is not smooth. The motion appears to be "rough" or jerky”.
Do the following Service Codes and procedures:
 Code 33 Software Identification. This is needed if you call Customer Service
 Code 11 Measure's the backlash in the system. Only used on machines with Dual Feedback
systems
 Code 12 Feed Forward Constant. High feed forward constants will cause an unstable servo
system
 Code 127 Measure's the backlash in the system. Only used on machines with no Dual Feedback
 Code 128 Enter backlash compensation
 Code 100 Axis open loop test. Used to check the maximum feedrate of an axis and if the
encoders are counting
Possible Cause
Check This
X, Y, and Z-axis Gibs are not
adjusted properly
Check the adjustment of the X, Y, and Z-axis Gibs using the X,
Y, and Z-axis Gib adjustment procedures.
Scale problem
Make sure that the Scale is installed correctly according to the
manufacturer’s instructions. Check for any loose brackets or
misalignment etc. Also, check to make sure the Scale
assemblies are functioning correctly. See Scales Section 4.6 &
4.7.
