Yadea C1S User Manual

Scooter structure diagram
1.Front fender 2. Headlight 3. Windshield 4. Rear-view mirror
5. Footplate 6.Seat cushion 7. Rear arm rest 8. Taillight
9. Rear license plate light 10. Rear fender 11. Motor
12. Rear shock absorber 13. Main stand 14. Footrest 15. Side stand
16. Charging hole 17. Battery 18. VIN number 19. Front tire
20. Front suspention 21. Front disc brake plate
1.Left rear brake lever 2. Grip 3. Left switch group
4. Speedometer 5. Right switch group
6. Throttle 7. Right front brake lever
11 12
3.SCOOTER STRUCTURE
1 2 3 4 5 76 8 9
10111615 14 13 122021 19 18 17
1 2 3 4 5 6 7

Yadea C1S Specifications

General

Battery Type	Lithium-ion
Range	up to 100 km
Brakes	Front and rear disc brakes
Category	Electric Scooter
Max Load	150 kg
Tire Size	12 inches
Charging Time	6 hours
