Yaesu SP-2000 - SP-2000 Product Features; Advanced Audio Filters; Audio Mute Function

Features ................................................................................................................................................................................2
Setup and Interconnections ..................................................................................................................................................3
Using the Extender Feet .......................................................................................................................................................3
Front Panel ...........................................................................................................................................................................4
Rear Panel ............................................................................................................................................................................ 5
Audio Filter Operation .........................................................................................................................................................6
Using the Speaker Mute Feature ..........................................................................................................................................7
Two Transceivers can be connected .....................................................................................................................................7
Supplied Parts ...................................................................................................................................................................... 8
Specifications ....................................................................................................................................................................... 8
Connection Diagram ............................................................................................................................................................9
Features
P 4.7” (120 mm) speaker with audio tailored for short-wave amateur radio communications.
P High-cut (2.4kHz, 1kHz, 700Hz) and Low-cut (500Hz, 300Hz) audio filters, with response selectable from the front panel.
P Front panel switch to select receiver input A or Receiver input B.
P Front panel mute switch.
P Front panel headphone jack is provided to monitor tone quality and filter adjustment.
Thank you for your purchase of the SP-2000 External Speaker.
This handsome and functional accessory is an outstanding addition to your next-generation FT-2000 station.
With its outstanding audio response and quality construction, it will truly compliment the elite-class Ham
station you have crafted. We trust you will enjoy the SP-2000 for many years to come.
Table of Contents
ENGLISH
