Table 3. Fault Codes (Continued)
Code Description
08961
One of the on/off valve coil is detected as shorted - (LH Node 4)
Node 4
12544
Wrong Battery voltage connected to truck, or out of range - (RH Node 5)
Node 5
12546
Battery empty or below maximum discharge level - (RH Node 5)
Node 5
12576
Traction U, V, W bridge voltage out of range (low or high) with MOSFETs off - (LH
Node 4)(RH Node 3)
Node 3 (4)
12576
Traction U, V, W bridge voltage out of range (low or high) with MOSFETs off - (Pump
Node 5)
Node 5
12592
Drive capacitor voltage too low or pre-charge not complete - (RH Node 3)
Node 3 (4)(5)
12812
Joystick detected fault in Traction
Axis - (Joystick Node 22)
Node 22
12824
Steering potentiometer is detected to be out of programmed range - (RH Node 3)
Node 3
12829
Driver for steer engage (A19 output) hardware fault - (Pump Node 5)
Node 5
12834
Electric brake coil driver is shorted, always disengaged - (LH Node 4)(RH Node 3)
Node 3 (4)
12835
Electric brake coil driver is damaged, no able to disengage the brake - (LH Node 4)(RH
Node 3)
Node 3 (4)
13312
Damaged on/off coil driver, unable to activate coil - (RH Node 3)
Node 3
13312
Damaged on/off coil driver, unable to activate coil - (LH Node 4)
Node 4
13316
Proportional lowering valve coil circuit open - (RH Node 3)
Node 3
13320
SV2A Tilt Forward valve coil circuit is open - (LH Node 4)
Node 4
13328
PV3 Aux proportional valve coil is open - (LH Node 4)
Node 4
17168
Device has indicated internal temperature exceeds 85°C or is lower than -40°C
Node 3 (4)(5)
21569
Contactor is open, not closing when energized - (RH Node 5)
Node 5
2200 YRM 1415 Troubleshooting
13
