Table 3. Fault Codes (Continued)
Code Description
21570
Contactor detected as stuck closed - (RH Node 5)
Node 5
21834
Joystick detected fault in Hoist Axis
Node 22
25186
Acceleration Parameter greater than preceding mode.
Node 3
29456
Device has indicated internal temperature exceeds 85°C or is lower than -40°C
Node 3 (4)
29456
Motor Encoder Locked (Encoder feedback not matching motor speed) (Pump Node 5)
Node 5
50100
Joystick detected fault in one of the auxiliary function buttons, stuck on- (Joystick Node
22)
Node 22
65513
Traction detects short in power MOSFETs before contactor closes. - (RH Node 3, LH
Node 4)
Node 3 (4)
65513
Traction detects short in power MOSFETs before contactor closes. - (RH Node 3)(LH
Node 4)
Node 5
65527
CAN messages are not being received from other nodes - (RH Node 3)(LH Node 4)
Node 3 (4)
65527
CAN messages are not being received from other nodes - (RH Traction Node 3, Pump
Node 5)
Node 3 (5)
65527
CAN messages are not being received from other nodes - (Pump Node 5)
Node 5
65527
CAN messages are not being received from other nodes - ( Dash Node 16)
Node 16
65280
The device, as indicated by node, has reported an internal (non-serviceable) failure of
its circuit
Node 3 (4)(5)(16)
65299
Battery Voltage (B+) is over or under voltage from nominal - (RH Node 3)
Node 3 (4)(5)
80244
The truck hours have hit a service reminder interval, perform routine service. - (Dash
Node 16)
__
80245
Operator has indicated failure on the startup checklist for truck - (Dash Node 16)
__
Troubleshooting 2200 YRM 1415
14
