STATUS
CODE
DISPLAY MESSAGE RECOVERY METHOD CIRCUIT
13320 13320 Automatic LH Traction
Node 4
DESCRIPTION BEHAVIOR
SV2A Tilt Forward valve coil circuit is open -
(LH Node 4)
Tilt forward inoperative, but other pump functions still
work.
Probable Causes and Test Procedures
1. Is only Tilt Fwd functionality disabled?
YES- Proceed to step 2.
NO- Review other hydraulic related codes and resolve
2. Verify SV2A Coil has power, measure wire 200 of coil, referenced to B−, is 36V present?
YES- Coil may be open, proceed to step 3 to test.
NO- Proceed to step 4.
3. Check coil resistance:
a. Measure across the coil of the valve in question, is it between 10 and 100 Ohms?
YES- Coil not at fault proceed to step 4.
NO- Coil shown to be open or shorted internally, replace coil.
4. Check coil wiring:
a. Measure from Pin 23 (CPS42) to SV2A coil connector (wire 803) for continuity.
YES- Proceed to step 4b.
NO- Repair wire, pin, or crimp (replace harness only if not repairable).
b. Check for shorted wiring, by measuring across coil connector and verifying resistance > 470k
Ohms.
YES- No wiring fault found, proceed to step 5.
NO- Determine location of short in wiring, separate and repair.
5. Verify if controller drive at fault:
a. Measure voltage across coil while activating coil function, does voltage transition to 0V to B+?
YES- Controller not at fault, replace coil.
NO- Controller faulted, contact Service Engineering.
2200 YRM 1415 Troubleshooting
77
