See Figure 31 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5,GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (H813) equipped with a Ku-
bota 3.6L diesel engine, manufactured before Feb-
ruary, 2012.
See Figure 32 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5,GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (H813), manufactured after
February, 2012, equipped with a Kubota 3.6L die-
sel engine.
See Figure 32 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6; GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (J813) equipped with a Ku-
bota 3.6L diesel engine.
See Figure 33 for lift trucks equipped with a Cum-
mins 4.5L diesel engine.
18. Disconnect exhaust pipes from exhaust mani-
folds. See Exhaust System Repair for procedures.
19. Remove radiator fan pulley, shroud, and fan as-
sembly. See section Cooling System
0700YRM1123 for removal procedures.
WARNING
All fuels are very flammable and can burn or
cause an explosion. DO NOT use an open flame to
check the fuel level or to check for leaks in the
fuel system.
No smoking.
Breathing fuel vapor may cause nausea, uncon-
sciousness or death. Long term exposure to gas-
oline vapors may cause liver or kidney damage
and cancer. Avoid breathing vapor.
20. Disconnect fuel lines at engine. Put caps on fuel
lines to prevent fuel leakage.
See Figure 25 for lift trucks equipped with a GM
4.3L gas or LPG engine and single hydraulic tank.
See Figure 26 for lift trucks equipped with a GM
4.3L LPG engine and dual hydraulic tanks.
See Figure 27 for lift trucks equipped with a Cum-
mins QSB 3.3L diesel engine.
See Figure 28 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5,GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (H813) equipped with a Ku-
bota 3.8L diesel engine, manufactured before Feb-
ruary, 2012.
See Figure 29 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5,GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (H813) equipped with a Ku-
bota 3.8L diesel engine, manufactured after Febru-
ary, 2012.
See Figure 30 for lift truck models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6; GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (J813) equipped with a Ku-
bota 3.8L diesel engine.
See Figure 31 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5,GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (H813) equipped with a Ku-
bota 3.6L diesel engine, manufactured before Feb-
ruary, 2012.
See Figure 32 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5,GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (H813), manufactured after
February, 2012, equipped with a Kubota 3.6L die-
sel engine.
See Figure 32 for lift trucks models GLP/
GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6; GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (J813) equipped with a Ku-
bota 3.6L diesel engine.
See Figure 33 for lift trucks equipped with a Cum-
mins 4.5L diesel engine.
21. Lift trucks equipped with GM 4.3L engine, remove
left side engine mount to access starter motor.
See Figure 25 or Figure 26.
22. Disconnect positive battery (B+) from starter mo-
tor.
23. Lift trucks equipped with GM 4.3L engine, remove
starter motor to reach four torque converter ac-
cess bolts. See Figure 25 or Figure 26.
Engine Replacement 0100 YRM 1243
52
