Table 2. Maintenance Schedule (See Figure 11, Figure 12, Figure 13, Figure 14, Figure 15) (Continued)
Item
No.
Description
8 hr or 1
day
3
350 hr or
2 month
3
2000 hr or
1 year
3
Procedure or
Quantity
Specification
13 Electrical Circuits X X Check Operation
Motor Brushes X Check Condition
Gauges, Horn, and
Fuses
X Check Operation
14 Articulating Chain
Anchors
6,7
L 2 Lube Fittings
Multipurpose Grease
5
15 Chain, Hose, and Wire
Sheaves
L Check Condition
Clean and Lubricate
Engine Oil
16 Reach Frame Thrust
Rollers
8
L A 2 Lube Fittings
Multipurpose Grease
5
17
Reach Cylinder Pivot Pins
8
(Rod and Tube Ends)
L Tilt Cylinders - 2 Fittings
Sideshift Cylinder -
4 Lube Fittings
Multipurpose Grease
5
18
Reach Arms
8
L 6 Lube Fittings
Multipurpose Grease
5
X=Check C=Change L=Lubricate A=Adjust
