ENGINE
42
SRM-2620ES, SRM-2620TES
T262XS, C262S
T262TXS, C262TS
6 ENGINE
( A ) Cylinder
( B ) Intake heat shield
( C ) Exhaust heat shield
( D ) Cylinder gasket
( E ) Piston ring
( F ) Piston
( G ) Needle bearing
( H ) Piston pin
( J ) Snap ring
( K ) Oil seal
( L ) Crankcase
( M ) Crankcase gasket
( N ) Ball bearing
( P ) Crankshaft assembly
( R ) Thrust washer
( S ) Woodruff key
(A)
(D)
(B)
(C)
(K)
(L)
(M)
(N)
(P)
(N)
(L)
(R)
(E)
(J)
(F)
(J)
(G)
(H)
(K)
(S)
