YAMADA 140 Series Instruction

1
1. Part Names
1.1 Part names
Fig. 1 and Fig. 2 show the names of each part used in the instructions in this manual. Use them as a reference.
Fig. 1 Part names
G3/8(F) air inlet
Plate
Pump base
Plunger connection
Plunger
Three studs
G3/4(F) material
outlet (with check
valve)
Bleeder valve
Air release plug
Inductor plate
(
flat
p
ackin
g
t
yp
e
)
Lift base Caster wheel with brake Caster wheel
Air cylinder
Air motor
Inductor plate
(
tube
p
ackin
g
t
yp
e
)
Lower pump
Silencer
Tie beam
Plug
