YAMADA NDP-5 series User Manual

12
1
11
1.5
.5.5
.5 NDP
NDPNDP
NDP-
--
-20
2020
20 ､
､､
､ 25 series
25 series25 series
25 series
A: Air Valve F : Pump Base
B: Reset Button G: Discharge Port
C: Out Manifold H: Intake Port
D: Out Chamber I: Lift Point
E: In Manifold J: Ground Connection Point
NDP-20-BA □ , NDP-20-BS □ BDP-20-BA □
NDP-25-BA □ , NDP-25-BS □
NDP-25-BF □
•Aluminum type ([ ]: Drum type B
BB
B)
Type BAC BAN BAE BAV BAT BAS BAH
Switching Portion ADC12
Fluid contact Portion ADC12 [ADC12, AC2A, SGP]
Diaphragm CR NBR EPDM FPM PTFE TPO TPEE
Ball/O Ring CR/NBR NBR EPDM FPM PTFE EPDM PTFE
Valve Seat SMS1025
Center Disk SUS316 A5056 SUS316
•Stainless-steel type ([ ]: Cast iron type)
Type BSC
[BFC]
BSN
[BFN]
BSE
[BFE]
BSV
[BFV]
BST
[BFT]
BSS
[BFS]
BSH
[BFH]
Switching Portion ADC12
Fluid contact Portion SCS14 [S45C]
Diaphragm CR NBR EPDM FPM PTFE TPO TPEE
Ball/O Ring CR/NBR NBR EPDM FPM PTFE EPDM PTFE
Valve Seat SUS316
Center Disk SUS316
*Cast iron casing is available from NDP-25 series until NDP-80 series.
