YAMADA NDP-5 series User Manual

33
■
■■
■ NDP
NDPNDP
NDP-
--
-25 (plastic type) series
25 (plastic type) series25 (plastic type) series
25 (plastic type) series
NDP-25
Type
BP □
BPT
BV □
BVT
Nominal Diameter
1˝
(25mm)
Suction
Port
Fluid
Connection
Discharge
Port
E.C. Countries BSP1 ″
Other Countries Rc1 ″
DIN Flange available
Supply
Port
Rc3/8˝
Air
Connection
Exhaust
Port
Rc3/4˝
Nominal Air Pressure
0.2~0.7MPa
(2~7kgf/cm
2
)
Maximum
Discharge Pressure
0.7MPa
(7kgf/cm
2
)
Discharge Volume/Stroke 600mL 500mL 600mL 500mL
Maximum
Discharge Volume
150L/min
Maximum
Air Consumption
1400L/min (ANR) 1600L/min (ANR) 1400L/min (ANR) 1600L/min (ANR)
Slurry Limitation 3mm or less
Limitation of Viscosity
Suction Lift 5Pa·s or below (5000Cp)
Force In 10Pa·s or below (10.000Cp)
Temp.
0~70 ˚C
[32~158 ˚ F ]
Operating
Ambient
Temperature
Range
Fluid
Temp.
0~60 ˚C [32~140 ˚ F ] PP
0~80 ˚C [32~176 ˚ F ] PVDF
Operating Noise 89dB
Weight 11.0kg 13.5kg
■
■■
■ NDP
NDPNDP
NDP-
--
-40 series
40 series40 series
40 series
NDP-40
Type
BA □
BAT
BS □
BST
BF □
BFT
BP □ /BV □
BPT / BVT
Nominal Diameter
1·1/2 ″
(40mm)
Suction
Port Fluid
Connection
Discharge
Port
Equivalent to
JIS flange 10K40A
Rc1·1/2˝
Equivalent to
JIS flange 10K40A
Supply
Port
Rc1/2˝
Air
Connection
Exhaust
Port
Rc1˝
Normal Air Pressure
0.2~0.7MPa
(2~7kgf/cm
2
)
0.2~0.7MPa
(2~7kgf/cm
2
)
Maximum
Discharge Pressure
0.7MPa
(7kgf/cm
2
)
0.7MPa
(7kgf/cm
2
)
Discharge Volume/Stroke 2800mL 1400mL 2800mL 1400mL 2800mL 1400mL 2800mL 1400mL
Maximum
Discharge Volume
380L/min 340L/min 380L/min 340L/min 380L/min 340L/min 380L/min 340L/min
Maximum
Air Consumption
3500
L/min
(ANR)
2500
L/min
(ANR)
3500
L/min
(ANR)
2500
L/min
(ANR)
3500
L/min
(ANR)
2500
L/min
(ANR)
3000
L/min
(ANR)
3000
L/min
(ANR)
Slurry Limitation 7mm or less
Limitation of Viscosity
Suction Lift 10Pa·s or below (10.000Cp)
Force In 30Pa·s or below (30.000Cp)
Temp.
0~70 ˚C
[32~158 ˚ F ]
Operating
Ambient
Temperature
Range
Fluid
Temp.
Diaphragm materials NBR/CR : 0~70˚C [32~158˚ F ]
EPDM : -20~80˚C [1~176˚ F ]
TPEE/TPO/PTFE : 0~100˚C [32~212˚ F ]
FPM : -10~120 ˚C [14~248˚ F ]
0~60 ˚C [32~140 ˚ F ] PP
0~80 ˚C [32~176 ˚ F ] PVDF
Operating Noise 82dB 82dB
Weight 27kg 43kg 47kg 27kg(PP) 32kg(PVDF)
