YAMADA NDP-5 series User Manual

34
■
■■
■ NDP
NDPNDP
NDP-
--
-50 series
50 series50 series
50 series
NDP-50
Type
BA □
BAT
BS □
BST
BF □
BFT
BP □
BPT
BV □
BVT
Nominal Diameter
2˝
(50mm)
Suction
Port
Fluid
Connection
Discharge
Port
Equivalent to JIS flange 10K50A Rc2˝ Equivalent to JIS flange 10K50A
Supply
Port
Rc3/4˝
Air
Connection
Exhaust
Port
Rc1˝
Nominal Air Pressure 0.2~0.7MPa (2~7kgf/cm
2
) 0.2~0.7MPa (2~7kgf/cm
2
)
Maximum
Discharge Pressure
0.7MPa
(7kgf/cm
2
)
0.7MPa
(7kgf/cm
2
)
Discharge Volume/Stroke 4300mL 2100mL 4300mL 2100mL 4300mL 2100mL 4300mL 2100mL 4300mL 2100mL
Maximum
Discharge Volume
600
L/min
580
L/min
600
L/min
580
L/min
600
L/min
580
L/min
600
L/min
560
L/min
600
L/min
560
L/min
Maximum
Air Consumption
4500
L/min
(ANR)
5500
L/min
(ANR)
4500
L/min
(ANR)
5500
L/min
(ANR)
4500
L/min
(ANR)
5500
L/min
(ANR)
5000
L/min
(ANR)
5000
L/min
(ANR)
5000
L/min
(ANR)
5000
L/min
(ANR)
Slurry Limitation 8mm or less
Limitation of Viscosity
Suction Lift 10Pa·s or below (10.000Cp)
Force In 30Pa·s or below (30.000Cp)
Temp.
0~70 ˚C [32~158 ˚ F ]
Operating
Ambient
Temperature
Range
Fluid
Temp.
Diaphragm materials
NBR/CR : 0~70˚C [32~158˚ F ]
EPDM : -20~80˚C [1~176˚ F ]
TPEE/TPO/PTFE : 0~100˚C [32~212˚ F ]
FPM : -10~120 ˚C [14~248˚ F ]
0~60 ˚C [32~140 ˚ F ] PP
0~80 ˚C [32~176 ˚ F ] PVDF
Operating Noise 82dB 82dB
Weight 36kg 63kg 64kg 37kg 42kg
■
■■
■ NDP
NDPNDP
NDP-
--
-80 series
80 series80 series
80 series
NDP-80
Type
BA □
BAT
BS □
BST
BF □
BFT
BP □
BPT
Nominal Diameter
3˝
(80mm)
Suction
Port Fluid
Connection
Discharge
Port
Equivalent to JIS flange 10K80A Rc3˝
Equivalent to JIS flange
10K80A
Supply
Port
Rc3/4˝
Air
Connection
Exhaust
Port
Rc1˝
Normal Air Pressure 0.2~0.7MPa (2~7kgf/cm
2
)
0.2~0.7MPa
(2~7kgf/cm
2
)
Maximum
Discharge Pressure
0.7MPa
(7kgf/cm
2
)
0.7MPa
(7kgf/cm
2
)
Discharge Volume/Stroke 8500mL 3800mL 8500mL 3800mL 8500mL 3800mL 8500mL 3800mL
Maximum
Discharge Volume
800L/min 640L/min 800L/min 640L/min 800L/min 640L/min 800L/min 600L/min
Maximum
Air Consumption
6000
L/min
(ANR)
5500
L/min
(ANR)
6000
L/min
(ANR)
5500
L/min
(ANR)
6000
L/min
(ANR)
5500
L/min
(ANR)
5500
L/min
(ANR)
5000
L/min (ANR)
Slurry Limitation 10mm or less
Limitation of Viscosity
Suction Lift 10Pa·s or below (10.000Cp)
Force In 30Pa·s or below (30.000Cp)
Temp.
0~70 ˚C [32~158 ˚ F ]
Operating
Ambient
Temperature
Range
Fluid
Temp.
Diaphragm materials NBR/CR : 0~70˚C [32~158˚ F ]
EPDM : -20~80˚C [1~176˚ F ]
TPEE/TPO/PTFE : 0~100˚C [32~212˚ F ]
FPM : -10~120 ˚C [14~248˚ F ]
0~60 ˚C
[32~140 ˚ F ]
Operating Noise 81dB 81dB
Weight 62kg 104kg 110kg 64kg
