01V96
46
Note: See parts list for details of circuit board component parts.
DCCOM (AC) Circuit Board (X3434C0) ........................................ 46
DCCOM (DCA 1/5) Circuit Board (X3434C0) ............................... 47
DCD Circuit Board (X3858B0) .................................................. 48/49
FD Circuit Board (X3423B0) .................................................... 50/52
HACOM (ADA) Circuit Board (X3422B0) ................................. 54/56
HACOM (HA) Circuit Board (X3422B0).................................... 58/60
MAIN Circuit Board (X3421B0) ...................................... 62/64/66/68
PNCOM (LCD) Circuit Board (X3424B0) ...................................... 75
PNCOM (PN1 (1/2, 2/2)) Circuit Board (X3424B0) .................. 70/72
PNCOM (PN2) Circuit Board (X3424B0) ....................................... 74
CIRCUIT BOARDS
Component side
DCCOM (AC) Circuit Board
2NAP-V989570-2 2 (J, U, V models)
2NAP-V989570-2a 2 (H, B, W K models)
（部品側）
to Power Transformer
POWER ON/OFF
to AC Inlet Assembly
not installed
注：シートの部品詳細はパーツリストをご参照下さい。
（シート基板図）
To Next Page
