Yamaha 115C - Oil Level Indicator

E
3-8
1,500 cm
3
(1.6 US qt,
1.31 Imp qt)
or less
EMU01543
Oil Level Indicator
The various oil level system functions are as follows:
Remarks
Oil level indica-
tor (Digital
tachometer)
Oil level indica-
tor (Analog
tachometer)
Engine oil
tank
Remote oil
tank
Green
Red Yellow Green
Yellow
Red
More than
300 cm
3
(0.32 US qt,
0.26 Imp qt)
300 cm
3
(0.32 US qt,
0.26 Imp qt)
or less
More than
300 cm
3
(0.32 US qt,
0.26 Imp qt)
300 cm
3
(0.32 US qt,
0.26 Imp qt)
or less
More than
1,500 cm
3
(1.6 US qt,
1.31 Imp qt)
More than
1,500 cm
3
(1.6 US qt,
1.31 Imp qt)
1,500 cm
3
(1.6 US qt,
1.31 Imp qt)
or less
• No refilling necessary.
• Add oil, refer to
“FILLING OIL.”
• Check oil filter for clogging.
• Check battery cable con-
nection.
• Buzzer will sound.
• Engine speed is automati-
cally reduced to about
2,000 r/min.
• Oil has not been added.
• Buzzer will sound.
• Engine speed is automati-
cally reduced to about
2,000 r/min.
• Refer to Chapter 5.
