Trouble Recovery
73
3. Remove the starter/flywheel cover after
removing the bolt(s).
4. Prepare the engine for starting. For fur-
ther information, see page 36. Be sure
the engine is in neutral and that the clip
is attached to the engine shut-off switch.
The main switch must be “” (on), if
equipped.
5. If equipped the choke knob, pull out it
when the engine is cold. After the engine
starts, gradually return the choke knob
to its home position as the engine warms
up.
6. Insert the knotted end of the emergency
starter rope into the notch in the flywheel
rotor and wind the rope several turns
around the flywheel clockwise.
7. Give a strong pull straight out to crank
1. Start-in-gear protection cable
ZMU03740
1
ZMU03741
ZMU03742
ZMU02334
ON STARTOFF
ZMU01906
ZMU04119
