Yamaha 2B User Manual

GB
4-10
EMK36010
CLEANING AND ADJUSTING SPARK
PLUG
The spark plug is an important engine
component and is easy to inspect. The
condition of the spark plug can indicate
something about the condition of the
engine. For example, if the center elec-
trode porcelain is very white, this could
indicate an intake air leak or carburetion
problem in that cylinder. Do not attempt
to diagnose any problems yourself.
Instead, take the outboard motor to a
Yamaha dealer. You should periodically
remove and inspect the spark plug
because heat and deposits will cause the
spark plug to slowly break down and
erode. If electrode erosion becomes
excessive, or if carbon and other deposits
are excessive, you should replace the
spark plug with another of the correct
type.
Before fitting the spark plug, measure the
electrode gap with a wire thickness
gauge; adjust the gap to specification if
necessary.
When fitting the plug, always clean the
gasket surface and use a new gasket.
Wipe off any dirt from the threads and
screw in the spark plug to the correct
torque.
Standard plug gap:
Refer to SPECIFICATIONS, Page 4-1.
Standard plug torque:
Refer to SPECIFICATIONS, Page 4-1.
Standard spark plug:
Refer to SPECIFICATIONS, Page 4-1.
6A1-9-7LA0-4B 3/7/02 12:17 PM Page 132

Yamaha 2B Specifications

General

Engine Type	2-stroke
Fuel Type	Gasoline
Oil Type	2-stroke outboard motor oil
Mixing Ratio	50:1
Ignition System	CDI
Starting System	Manual
Operation Method	Tiller handle
Gear Ratio	2.08:1
Max Power Output	2 HP
Full Throttle RPM Range	4, 500 - 5, 500 RPM
Fuel Tank Capacity	1.2 liters
Weight	9.8 kg
Shaft Length	15 inches
