Procedure
1) Remove the top cowling.
2) Remove the starter by removing the
bolts.
3) Prepare the engine for starting. See
STARTING ENGINE for procedures.
Be sure the engine is in Neutral.
4) To start the engine with emergency
starter rope, insert the knotted end of
the rope into the notch in the flywheel
rotor and wind the rope several turns
clockwise. Then, give a strong pull
straight out to crank the engine.
Repeat if necessary.
3 4/5
4/5
