7-3
DIGITAL NETWORK PREMIUM GAUGE COMPATIBLE MODELS
The following models can accept Digital Network Premium Gauge (6Y9 new network system).
These engines can accept the conventional Digital Network Gauges (6Y8) as well.
For further information, see the applicable models service guide, installation manual, etc.
DIGITAL NETWORK PREMIUM GAUGE APPLICATION
With TFT-LCD color screen, arrow key, and USB port for triple engine application.
Global model US/CA/ANZ model Remarks
F/FL200G F/LF200CA
F/FL225F F/LF225CA
F/FL250D F/LF250CA
F/FL300B F/LF300CA
F/FL350A F/LF350CA/B For 2011 and later models
Ref. No. Part name Part No. Remarks
1 Premium color gauge ASSY 6Y9-83710-11 w/ screen cover (6Y9-87278-00)
1
SET
MENU
CANCEL

Yamaha 30HWH Specifications

General

Horsepower	30 hp
Full Throttle Operating Range	5000 - 6000 rpm
Starting System	Electric
Shaft Length	Long
Displacement	496 cc
