Yamaha 30HWH User Manual

7-36
Fuel tank 1
GPS
31
(*1) For previous digital electronic controlled engine (*2) For 6Y9 network system
30
54
16
16
27
28
54
SPEED
TAC H
SPEED/FUEL
TAC H
16
ECM
1
19
(*2)
13
13
14
12
(*1)
41
42
(*1)
40
16
22
9
13
13
13
12
2nd station helm
Main station helm
(GND)
(+)
Not used
NETWORK WIRING DIAGRAMS
DUAL STATION W/ 6Y8 GAUGE SINGLE ENGINE APPLICATION

Yamaha 30HWH Specifications

General

Horsepower	30 hp
Full Throttle Operating Range	5000 - 6000 rpm
Starting System	Electric
Shaft Length	Long
Displacement	496 cc
