OUTBOARD MOTOR DIMENSIONS
OVERALL DIMENSIONS (4-STROKE)
Global model
(US, CA,
ANZ model)
Symbol
F/FL225FET
(F/LF225CA)
F/FL250DET
(F/LF250CA)
F/FL300BET
(F/LF300CA)
F/FL350AET
(F/LF350CB)
L1 mm (in) 728 (28.7) 776 (30.6)
L2 mm (in) 230 (9.1) 255 (10.0)
L3 mm (in) — —
L4 mm (in) 673 (26.5) 732 (28.8)
L5
S
mm (in)
——
L——
X 59 (2.3) 48.4 (1.9)
U 59 (2.3) 48.4 (1.9)
L6
S
mm (in)
——
L——
X 1155 (45.5) 1193 (47.0)
U 1272 (50.1) 1310 (51.6)
L7 mm (in) 639 (25.2) 712 (28.0)
L8 mm (in) 240 (9.4) 258 (10.2)
L9
S
mm (in)
——
L——
X 53 (2.1) 56 (2.2)
U 59 (2.3) 62 (2.4)
L10 mm (in) 75 (3.0) 73 (2.9)
H1
S
mm (in)
——
L——
X 1078 (42.4) 1098 (43.2)
U 1205 (47.4) 1225 (48.2)
H2 mm (in) 812 (32.0) 909 (35.8)
H3 mm (in) 216 (8.5) 229 (9.0)
H4
S
mm (in)
——
L——
X 643 (25.3) 637 (25.1)
U 770 (30.3) 764 (30.1)
H5 mm (in) — —
H6
S
mm (in)
——
L——
X 847 (33.3) 864 (34.0)
U 924 (36.4) 941 (37.0)
H7 mm (in) 510 (20.1) 588 (23.1)
H8 mm (in) 48 (1.9) 65 (2.6)
H9 mm (in) 951 (37.4) 1041 (41.0)
H10 mm (in) 45 (1.8) 49 (1.9)
H11
S
mm (in)
——
L——
X 25 (1.0) 26 (1.0)
U 25 (1.0) 26 (1.0)
W1 mm (in) 317 (12.5) 317 (12.5)
W2 mm (in) — —
W3 mm (in) — —
W4 mm (in) — —
W5 mm (in) 454 (17.9) 475.6 (18.7)
W6 mm (in) — —
A1 degree 32 32
A2 degree 67 70
A3 degree 3 3
T1 mm (in) 724 (28.5) 723.9 (28.5)
