Yamaha 40VMHD - Portable Fuel Tanks (Typical)

9-7
PORTABLE FUEL TANKS (TYPICAL)
No. Part No.
Capacity
L (US gal)
Material Description
1 6YL-W2420-J3 12 (3.2) Plastic w/ fuel gauge
2 6YL-24201-23 12 (3.2) Plastic US/CA meeting with EPA regulations, w/ fuel gauge
3
6YJ-24201-00 24 (6.3) Plastic For JPN, With JCI label, w/ fuel gauge
6YJ-24201-80 24 (6.3) Plastic With tag and exclusive filler structure banning use of leaded fuel (EU)
4
6YK-24201-03 25 (6.6) Plastic With fuel gauge
6YK-24201-10 25 (6.6) Plastic With label and exclusive filler structure banning use of leaded fuel
6YK-24201-21 25 (6.6) Plastic For kerosene
5 6YK-24201-43 25 (6.6) Plastic US/CA meeting with EPA regulations, w/ fuel gauge
123
mm (in.)mm (in.)mm (in.)
363 (14.3)
265 (10.4) 230 (9.1)
363 (14.3)
265 (10.4) 232 (9.1)
455 (17.9)
252 (9.9)314 (12.4)
45
mm (in.)mm (in.)
536 (21.1)
233 (9.2)
362 (14.3)
545 (21.5)
233 (9.2)
362 (14.3)
