What to do if Yamaha 40XMH Outboard Motor fuel management gauge shows incorrect fuel consumption?
If the fuel management gauge shows incorrect fuel consumption, the engine recognition might be wrong (especially for multi-applications). To fix this, default the engine number and turn the key switch on in order from the portside engine to re-memorize each engine number.
What to do if the Yamaha 40XMH gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or, if necessary, replace the gauge itself.
Why Yamaha Outboard Motor illumination does not light?
If the illumination does not light, it could be due to a lack of electrical power or a damaged gauge. You should try replacing the fuse, connecting the couplers securely, replacing the damaged wire or hub, or replacing the gauge.
How to fix Yamaha 40XMH Outboard Motor tachometer showing incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong (especially for multi-applications). To correct this, push the 'SET' button for 10 seconds to default the engine number, then memorize each engine number again.
What causes Yamaha Outboard Motor fuel management gauge to show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting may be wrong (specifically for SQR Fuel mgt Gauge). Fill the tank with fuel, and set the correct fuel tank capacity.
What to do if Yamaha Outboard Motor gauge shows “----”?
If the gauge displays '----', it indicates that the digital signal is not being received. Check that the couplers are securely connected and replace any damaged bus wires or hubs.
Why Yamaha 40XMH Speedometer or Comb. Speedometer & Fuel mgt gauge shows incorrect fuel level?
If the speedometer or combination speedometer & fuel management gauge shows an incorrect fuel level, the fuel sensor selection is likely wrong. Set up the fuel sensor to the correct resistance.
How to fix Yamaha 40XMH Outboard Motor trim gauge showing incorrect position?
If the trim gauge shows an incorrect position, the initial position setting might be wrong, or the trim sender could be damaged. Put the motor in the fully trimmed-in position and reset the initial (zero) trim angle. If that doesn't work, replace the trim sender.
Why Yamaha 40XMH gauge operates unstably?
If the gauge operates unstably, it could be because a resistor is not connected to the ending hubs. Connect the gray 6-pin cap to the ending multi-hubs.
What causes Yamaha 40XMH Outboard Motor gauge response to be poor or down?
If the gauge response is poor or down, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Try replacing the unit or removing the heavy signal output unit.
Important signs to handle the crate. Read and understand pictographs to avoid damage.
Step-by-step guide for safely removing the outboard motor from its shipping crate.
Guidance on determining the correct height and position for mounting the outboard motor on the transom.
Ensures correct motor height for optimal performance and prevents water intrusion into engine.
Procedure for setting toe-out position for optimal wake meeting and motor spacing.
Instructions for installing the remote oil tank for 2-stroke V4 and V6 oil injection engines.
Detailed measurements and specifications for various outboard motor models.
Defines various dimensions and symbols related to the outboard motor clamp bracket.
Overview of Yamaha propeller types, designs, and their intended applications.
Guidance on choosing the correct propeller pitch and series for optimal performance.
Tables detailing propeller applications by engine size and model.
Engine RPM ranges for correct propeller selection at Wide Open Throttle.
Details on Yamaha's throttle control systems and available remote control models.
Information on various switch panels and their functions for remote control systems.
Guidelines for selecting and routing remote control cables for proper operation.
Describes optional wire harnesses for connecting remote control and instrument systems.
Describes the features and functions of the multi-function tiller handle assembly.
Illustrates the electrical connections for multi-function tiller handles in the US market.
Explains how to adjust steering friction for optimal tiller handle operation.
Procedures for installing gauges on the boat's control panel for optimal visibility.
Details on analog tachometers for monitoring engine speed and performance.
Information on digital tachometers, including features like hour meter and trim indicator.
Functions and applications of the fuel management gauge for monitoring fuel consumption.
Representative wiring diagrams for various Yamaha instruments and systems.
Lists Yamaha models that are compatible with the digital network gauge system.
Overview of applications for square and round style digital network gauges.
Detailed wiring diagrams for various digital network gauge system configurations.
Common issues and solutions for the digital network gauge system and its components.
Guidance on selecting the correct battery capacity and type for reliable engine starting.
Instructions for wiring the battery system, including single and multi-engine setups.
Explains how to interpret Yamaha outboard motor model names and codes.
Specifies vacuum pressure standards for the fuel system to ensure proper engine operation.
A checklist for pre-delivery inspections to ensure customer satisfaction and proper operation.
Provides serial number information for 2009 Yamaha outboard motors.
Important signs to handle the crate. Read and understand pictographs to avoid damage.
Step-by-step guide for safely removing the outboard motor from its shipping crate.
Guidance on determining the correct height and position for mounting the outboard motor on the transom.
Ensures correct motor height for optimal performance and prevents water intrusion into engine.
Procedure for setting toe-out position for optimal wake meeting and motor spacing.
Instructions for installing the remote oil tank for 2-stroke V4 and V6 oil injection engines.
Detailed measurements and specifications for various outboard motor models.
Defines various dimensions and symbols related to the outboard motor clamp bracket.
Overview of Yamaha propeller types, designs, and their intended applications.
Guidance on choosing the correct propeller pitch and series for optimal performance.
Tables detailing propeller applications by engine size and model.
Engine RPM ranges for correct propeller selection at Wide Open Throttle.
Details on Yamaha's throttle control systems and available remote control models.
Information on various switch panels and their functions for remote control systems.
Guidelines for selecting and routing remote control cables for proper operation.
Describes optional wire harnesses for connecting remote control and instrument systems.
Describes the features and functions of the multi-function tiller handle assembly.
Illustrates the electrical connections for multi-function tiller handles in the US market.
Explains how to adjust steering friction for optimal tiller handle operation.
Procedures for installing gauges on the boat's control panel for optimal visibility.
Details on analog tachometers for monitoring engine speed and performance.
Information on digital tachometers, including features like hour meter and trim indicator.
Functions and applications of the fuel management gauge for monitoring fuel consumption.
Representative wiring diagrams for various Yamaha instruments and systems.
Lists Yamaha models that are compatible with the digital network gauge system.
Overview of applications for square and round style digital network gauges.
Detailed wiring diagrams for various digital network gauge system configurations.
Common issues and solutions for the digital network gauge system and its components.
Guidance on selecting the correct battery capacity and type for reliable engine starting.
Instructions for wiring the battery system, including single and multi-engine setups.
Explains how to interpret Yamaha outboard motor model names and codes.
Specifies vacuum pressure standards for the fuel system to ensure proper engine operation.
A checklist for pre-delivery inspections to ensure customer satisfaction and proper operation.
Provides serial number information for 2009 Yamaha outboard motors.
General| Engine Type | 2-Stroke |
|---|---|
| Horsepower | 40 hp |
| Starting System | Manual |
| Bore x Stroke | 80.0 x 70.0 mm |
| Shaft Length | 20 in |
| Cooling System | Water |
