2-1
GB
101102*
q
w
e
r
y
t
u
i
o
!0
!1
!2
EMU01206
MAIN COMPONENTS
1 Top cowling
2 Tilt support lever
3 Trim angle adjusting rod
4 Anti cavitation plate
5 Trim tab (Anode)
6 Cooling water inlet
7 Propeller
8 Battery cable
9 Anode
0 Clamp bracket
q Choke knob
w Cowling lock lever
e Remote control box
r Trim meter
t Fuel tank
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
55BET
!3
701061
!4
801011
YAMAHA
!5
902056
*
*
697-9-75 (GB,F,ES)2A 5/8/01 2:54 PM Page 24
