Yamaha 8 - Tilting the Outboard Motor Up and Down

Operation
38
the bow is greatly increased, heightening the
danger of “bow steering” and making opera-
tion difficult and dangerous.
T
IP:
Depending on the type of boat, the outboard
motor trim angle may have little effect on the
trim of the boat when operating.
EMU27922
Tilting up and down
If the engine will be stopped for some time or
if the boat is moored in shallows, the out-
board motor should be tilted up to protect the
propeller and lower casing from damage by
collision with obstructions, and also to re-
duce salt corrosion.
WARNING
EWM00221
Be sure all people are clear of the out-
board motor when tilting up and down.
Body parts can be crushed between the
motor and the clamp bracket when the
motor is trimmed or tilted.
WARNING
EWM00230
Leaking fuel is a fire hazard. Tighten the
air vent screw and place the fuel cock in
the closed position if the outboard motor
will be tilted for more than a few minutes.
Otherwise fuel may leak.
NOTICE
ECM00231
●
Before tilting the outboard motor, fol-
low the procedure under “Stopping en-
gine” in this chapter. Never tilt the
outboard motor while the engine is run-
ning. Severe damage from overheating
can result.
●
Do not tilt up the engine by pushing the
tiller handle because this could break
the handle.
●
Keep the power unit higher than the
propeller at all times. Otherwise water
could run into the cylinder and cause
damage.
●
The outboard motor cannot be tilted
when in reverse or when the outboard
motor is turned 180° (facing the rear).
EMU32662
Procedure for tilting up (manual tilt
models)
1. Place the gear shift lever in neutral.
2. Disconnect the fuel line from the out-
board motor.
