Yamaha AR195 User Manual

Equipment operation
64
Anchor light (SX195/SX190)
The boat is equipped with a removable an-
chor light.
The anchor light is stored in the ski locker.
To set up the anchor light:
(1) Open the ski locker. (See page 58 for ski
locker opening and closing procedures.)
1 Ski locker
(2) Remove the anchor light from the anchor
light holder.
1 Anchor light holder
2 Anchor light
(3) Open the cap of the anchor light socket,
fit the protrusion on the anchor light into
the slot in the socket, and then install the
light into the socket.
1 Cap
2 Slot
3 Protrusion
(4) Fit anchor light stopper into the anchor
light socket.
1 Anchor light stopper
To store the anchor light:
(1) Pull anchor light stopper upward, remove
the anchor light, and then close the cap of
the anchor light socket.
(2) Install the anchor light into the anchor
light holder, and then close the ski locker.
1
1
2
2
3
1
1
SportsBoat_F4B10.book Page 64 Thursday, June 2, 2016 10:08 AM
Downloaded from ManualsNet.com search engine

Yamaha AR195 Specifications

General

Draft	15 in
Dry Weight	2, 100 Lbs
Seating Capacity	8 persons
Fuel Capacity	30 gal
Engine Type	4-cylinder, 4-stroke
Horsepower	180 HP
Jet Pump	155mm High-Pressure
Drive System	Jet Drive
Beam	8 ft, 2 in
Engine	Yamaha Marine Engine
