Keyboard Arp & Drum Pad Owner’s Manual 3
This display lets you control Arpeggio playback of the synthesizer. Select the desired Arpeggio Type (
5) then tap the keyboard at the bottom.
1 Keyboard
Tapping or touching a key will transmit the corresponding MIDI note message. Dragging this area leftward or rightward will scroll through the entire keyboard.
2 KEYBOARD SCROLL LOCK
Tapping here locks or unlocks keyboard scrolling. The red color indicates the locked condition.
3 MODULATION
Tapping this transmits Modulation Wheel messages via MIDI.
4 Slider and PITCH/VELOCITY/ASSIGN1/ASSIGN2
When “PITCH” is selected, the Slider can be used as the Pitch Bend wheel. When “VELOCITY” is selected, holding the Slider and tapping any key transmits the
MIDI note message via the Velocity according to the Slider position. When “ASSIGN1” or “ASSIGN2” is selected, tapping the Slider transmits the MIDI message
specified in the Utility window.
Keyboard display
1
23
#
$
6
4
1
23
!
!
@
@
#
$
6
-1
7
7
8
8
9
9
)
)
4
5
5
