Yamaha Aventage RX-A770 User Manual

En 133
Language
Select an on-screen menu language.
Settings
English
, 日本語 , Français, Deutsch, Español, Русский, Italiano, 中文
X
The information on the front display is provided in English only.
Viewing information about the unit
(Information menu)
You can view information about the unit using the TV screen.
1
Press ON SCREEN.
2
Use the cursor keys to select “Information” and press ENTER.
3
Use the cursor keys (e/r) to select an information type.
4
To exit from the menu, press ON SCREEN.

Yamaha Aventage RX-A770 Specifications

General

Channels	7.2
HDMI Outputs	2
HDMI Version	2.0
Network Connectivity	Ethernet, Wi-Fi
Multi-Room Audio	MusicCast
CINEMA DSP	Yes
DSP Programs	17
Virtual Presence Speaker	Yes
Virtual Surround Back Speaker	Yes
Dialogue Lift	Yes
Dialogue Level Adjustment	Yes
SILENT CINEMA / Virtual CINEMA DSP	Yes
AirPlay	Yes
HDMI eARC	Yes
HDMI Pass-through	Yes
HDMI Upscaling	Yes (4K)
Component Video Input/Output	2 / 1
Digital Audio Input/Output: Coaxial	2 / 0
Phono Input	Yes
Speaker Output	7
Zone 2 Audio Output	Yes
AV Front Input	Yes
FM/AM Tuner	Yes
On-Screen Display	Yes
SCENE	4
App Control	Yes
Web Browser Control	Yes
RS-232C Interface	Yes
DC Out	Yes
Standby Power Consumption (IR only)	0.1 W
Bluetooth	Yes
MusicCast	Yes
Power Output (1kHz, 1ch driven)	160 W
Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)	160 W
Audio Formats Supported	Dolby TrueHD, DTS-HD Master Audio
Streaming Services	Spotify, Pandora, TIDAL, Deezer
File Format	WAV, MP3, AAC, FLAC, ALAC
Digital Audio Input/Output: Optical	2
Dimensions (W x H x D)	435 mm
Power Output (8 ohms, 20Hz-20kHz, 0.06% THD, 2-ch driven)	95 W (8 ohms, 20 Hz-20 kHz, 0.06 % THD, 2 ch driven)
