BB2004/BB2005
8
CIRCUIT DIAGRAM
OP AMP
OP AMP
OP AMP
OP AMP
REGULATOR
Electrolytic Capacitor Mylar Capacitor Ceramic Capacitor Tantalum Capacitor
FRONT
PICKUP
CIRCUIT BOARD
BASS
TREBLE
MID CUT SW.
MID CUT FREQ.
OUTPUT
JACK
MASTER
VOL.
DC9V
BALANCER
REAR
PICKUP
BAPJ-02
BB2004
（回路図）
