BB604/BB605
3
: New Parts RANK: Japan only
*
*
*
*
*
*
*
*
*
OVERALL ASSEMBLY BB604
A01 Neck Assembly YNS
A01 Neck Assembly WR
A01 Neck Assembly BL
A01b Seal (QC67600)
D01 Body
E01 Tuning Machine Assembly RM1243 (Gold) 2 09
E02 Tuning Machine Assembly RM1243L (Gold) 2 09
E04 Round Head Wood Screw 2.4X10 (Gold) 4 02
E05 String Guide Gold 05
E06 Spacer Black 01
E07 Oval Head Wood Screw 2.7X20 (Gold)
E08 Rod Cover Black 03
E09 Oval Head Wood Screw 2.1X10 FCM3BL Black 01
E10 Nut Urea 40mm (Ivory) 07
E11 Neck Plate Square (Gold) 05
E12 Oval Head Tapping Screw 4.0X45 (Gold) 4
E18 Bridge Assembly Diecast (Gold) 11
E19 Oval Head Tapping Screw 3.0X25 (Gold) 4
E21 Strings H4030 1set (QC35100)
E25 Strap Button ST-type (Gold) 2 02
E26 Oval Head Tapping Screw 3.0X25 (Gold) 2
E27 Spacer Felt (Black) 201
E28 Knob Assembly VK-3 H=16.5 (Gold) BAL,VOL,BASS,TREBLE,M-FQ 506
E28a Set Screw 4.0X6 (Gold) 5
E31 Back Cover Electrical (Black)
E33 Oval Head Wood Screw 2.7X13 FCM3BL Black 5 03
F01 Electrical Unit (QC67160)
F01a Circuit Board 1set
F01b Variable Resistor 500K ohm A+C CC BALANCER 05
F01c Variable Resistor 50K ohm B CC TREBLE
F01d Variable Resistor 20K ohm B M.VOLUME 04
F01e Hexagonal Nut with Volume 5
F01f Flat Washer with Volume 5
F01g Toothed Lock Washer with Volume 5
F01h Toggle Switch ON-ON (Black) MID FREQ.(ON-OFF)
F01i Toothed Lock Washer with Toggle Switch
F01j Flat Washer with Toggle Switch
F01k Hexagonal Nut with Toggle Switch
F07 Box for Dry Cell 04
F08 Pan Head Tapping Screw 3.0X8 FCM3BL Black 2
F12 Jack Gold 07
F12a Hexagonal Nut
F12b Toothed Lock Washer
F12c Rubber Ring
G01 Pickup Assembly S/C KPBO (Black) FRONT
G03 Pan Head Tapping Screw 2.6X35 FCM3BL Black 4 02
G04 Pickup Cushion 85X17X15 02
G05 Round Head Wood Screw 2.7X13 FCM33G for Earth Lug (Chrome) 03
G06 Pickup Assembly S/C KPBO (Black) REAR
G08 Pan Head Tapping Screw 2.6X35 FCM3BL Black 4 02
G09 Pickup Cushion 85X17X15 02
G10 Round Head Wood Screw 2.7X13 FCM33G for Earth Lug (Chrome) 03
H01 Accessory Unit G-1 1set 07
Cord D 05
Wrench #1.5
Wrench #5
Bridge Assembly Diecast (Gold) 11
B01 Bridge Base Gold 07
B02 Bridge Piece Assembly 1,2 (Gold) 1,2 Strings 2 05
B03 Bridge Piece Assembly 3,4 (Gold) 3,4 Strings 2 05
AAX33700
AAX33710
AAX33720
--
--
QC336300
QC336400
03704070
VB518400
VJ382000
03706320
CB821460
03706220
CB821090
AA819960
EN240050
QC347800
EN230130
--
BB802460
EN230130
VB793700
QC032200
--
QC677100
EB620020
--
QC671500
QC259400
QC672100
QC259500
--
--
--
QC677900
--
--
--
QA223300
QC025000
QA209900
--
--
--
QC670100
VJ388800
CB815450
EA620060
QC670200
VJ388800
CB815450
EA620060
QC354000
QA262600
--
--
QC347800
QC348000
NX818360
NX818370
REF NO.
PART NO. DESCRIPTION REMARKS
QTY
RANK
BB604
